Maximum number of positions: 24

Centerline Spacing: 5.08mm Spacing (0.200")

See DIMENSIONAL DRAWINGS

FEATURE:

with Mounting Screw

ELECTRICAL:

Voltage Rating: 300 VAC

Current Rating: 20 Amps

Wire Range Min / Max: 12-22AWG

MECHANICAL:

Torque: 5.0 lbs-in. Max.

MATERIAL:

Insulator Body Material: Polyamide, UL 94V-0

Terminal Screw Size: M3.0

Terminal Screw Material: Steel, Zinc Plated, "-" Slotted

Contact Block Material: Brass, (CuZn)

Contact Solder Pin Material: PhBz, (CuSn)

Mounting Flange Screw: Steel, Zinc Plated, "-" Slotted

Color: Green
