Maximum number of positions: 24

Centerline Spacing: 5.00mm Spacing (0.197")

See DIMENSIONAL DRAWINGS

FEATURE:

With Flange

ELECTRICAL:

Voltage Rating: 300 VAC

Current Rating: 15 Amps

Wire Range Min / Max: 12-28AWG

MECHANICAL:

Not Applicable

MATERIAL:

Insulator Body Material: Polyamide, UL 94V-0

Contact Clip Material: PhBz, Tin Plated

Wire Retention Spring: Stainless Steel

PRODUCT NOTES:

Compatible with the following headers:
Angled, Closed: AC1500
Horizontal, Closed: HC1500
Vertical, Closed: VC1500
Angled, Open: AO1500
Horizontal, Open: HO1500
Vertical, Open: VO1500
